Msi H310M PRO-M2 Motherboard INTEL

Msi H310M PRO-M2 Motherboard INTEL

Rs. 5,480.00
Rs. 20,000.00 Rs. 5,480.00
Sale Sold out
Taxes included. Shipping calculated at checkout.

Specifications

Processor Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
Chipset Intel® H310 Chipset This chipset is ME11 firmware based and doesn't feature SDA3.0
Memory
  • 2 x DDR4 memory slots, support up to 32GB
  • Supports DDR4 2666/ 2400/ 2133 MHz
  • Dual channel memory architecture
  • Supports non-ECC, un-buffered memory
  • Supports Intel® Extreme Memory Profile (XMP)
Slots
  • 1 x PCIe 3.0 x16 slot
  • 2 x PCIe 2.0 x1 slots
Onboard Graphics
  • 1x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz1
  • 1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz1
  • 1x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@30Hz1
*No Display support when using the Processor model with suffix “F”
  1. Supports up to 2 displays simultaneously
Storage Intel® H310 Chipset
  • 4 x SATA 6Gb/s ports1
  • 1 x M.2 slot (Key M)
  • Support up to PCIe 2.0 x4 and SATA 6Gb/s
  • Supports 2242/ 2260 /2280 storage devices
  1. SATA1 port will be unavailable when an M.2 SATA SSD is installed in the M2_1 slot.
USB Intel® H310 Chipset
  • 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors)
  • 6 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connectors)
Audio Realtek® ALC887 Codec
  • 7.1-Channel High Definition Audio
LAN 1 x Intel I219-V Gigabit LAN controller
Internal connectors
  • 1 x 24-pin ATX main power connector
  • 1 x 8-pin ATX 12V power connector
  • 4 x SATA 6Gb/s connectors
  • 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
  • 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports)
  • 1 x 4-pin CPU fan connector
  • 1 x 4-pin system fan connector
  • 1 x Front panel audio connector
  • 1 x Serial port connector
  • 2 x Front panel connectors
  • 1 x TPM module connector
  • 1 x Chassis Intrusion connector
  • 1 x Clear CMOS jumper
Back panel ports
  1. PS/2 Combo
  2. VGA
  3. HDMI
  4. USB 3.1 Gen1
  5. LAN
  6. HD Audio Connectors
  7. DVI-D
  8. USB 2.0
Dimensions
  • 9.1 in. x 7.3 in. (23.0 cm x 18.5 cm)
  • m-ATX Form Factor
Mounting 6 mounting holes
Operating System Support for Windows® 10 64-bit
Warranty 3 Years
Note ***Features, Price and Specifications are subject to change without notice.
